UNISTRUT
13/16” Series
P6917 5 Hole Gusset
•
Refer to Standard Dimensions for
width, thickness, hole diameters and
hole spacing
•
Call to specify material and finish
UNISTRUT
Fiberglass
20P2200 Slotted Channel
•
Wt/100 ft. (lbs.): 82
UNISTRUT
Fiberglass
20P2000 Single Channel
•
Patented flange profile
•
Area: 1.06”[2]
X - X Axis: I: 0.31 in[4]; R: 0.54”; C!:
0.70”; C2: 0.93”
Y - Y Axis: I: 0.42 in[4]; R: 0.63”; C:
0.82”
•
Wt/100 ft. (lbs.): 82
UNISTRUT
Fiberglass
20P2100 Back to Back
•
Patented flange profile
•
Area: 2.12”[2]
X - X Axis: I: 1.77 in[4]; R: 0.91”; C!:
1.63”; C2: 1.63”
Y - Y Axis: I: 0.85 in[4]; R: 0.63”; C: 0.82”
•
Wt/100 ft. (lbs.): 164
UNISTRUT
Fiberglass
Channel Nut - Heavy Duty
Heavy duty channel nuts are designed
to be used where high thread shear
values or spring nuts are required. They
can not be used with light duty 1000
series channel or SST profile channel.
•
Material: glass-reinforced polyure-
thane
•
Thread shear values shown represent a 3:1 safety factor
•
Wt/100 pcs. (lbs.): 5.7
UNISTRUT
Fiberglass
Channel Nut - Standard Duty
Standard Duty channel nuts are
designed for light duty applications that
do not require high thread shear values.
They can be used with both light duty
series 1000 and heavy duty series 2000
fiberglass channel.
•
Note: For use with SST profile channel
•
Material: glass-reinforced polyurethane
•
Thread shear values shown represent a 3:1 safety factor
•
Wt/100 pcs. (lbs.): 1.8
UNISTRUT
Fiberglass
Threaded rods
•
Material: Pultruded vinyl ester
resin and is gray in color
•
Ordered in eight foot lengths
•
Thread shear values shown represent a 3:1 safety factor
•
Wt/100 pcs. (lbs.): 3/8”-35, 1/2”-57
UNISTRUT
Fiberglass
6 Hole Gusset Tee
Wt/100 pcs. (lbs.): 50
Item #
UTP6917
Item #
UF20P-2200-20
Item #
UT20P-2000-20
Item #
UT20P-2100-20
Item #
Size
Thread Shear
(lbs.)*
Torque (ft./lbs.)
UTF375PU-CNHD
³⁄₈
”-16
1,400
8
UTF500PU-CNHD
¹⁄₂
”-13
1,400
8
Item #
Size Thread Shear (lbs.)* Torque (ft./lbs.)
UTF250PU-CN
¹⁄₄
”-20
460
2
UTF375PU-CN
³⁄₈
”-16
460
3
UTF500PU-CN
¹⁄₂
”-13
460
3
Item #
Size Thread Shear (lbs.)* Torque (ft./ lbs.)
UTF200-3827-96
³⁄₈
”-16
470
5
UTF200-3828-96
¹⁄₂
”-13
570
10
Item #
Wt/100 pcs (Lbs)
UR20P-2530
50
