Unistrut, Pipe Hangers & Caddy
Boise, ID 208-377-0158
Eugene, OR 541-342-3641
Idaho Falls, ID 208-522-7082
Medford, OR 541-779-0187
509
UNISTRUT
Concrete Inserts
P33XX
•
7/8” tall x 1-5/8” wide
•
Gauge: 12ga.
•
Same height as P 3300
•
Insert Length: 20’
•
Max. Allowable Point Load: 2,000 lbs.
•
Min. Spacing of Pt. Loads: 12”
•
Max. Allowable Uniform Load: 2,000 lbs.
•
No Closure Strip, No End Caps, W/Back Plates
•
Make sure to include Closure Strips
•
Call to specify material finish and length
UNISTRUT
Closure Strip
P3712P-Plastic
•
Material: Plastic
•
Color: Black.
•
Note: Use with P3170, P3270,
and P3370 series concrete insert.
•
Standard length: 10' (3m)
UNISTRUT
Concrete Inserts
End Cap Anchors
Note: End cap anchor for use with
1-5/8” wide standard Unistrut inserts
only
•
Use P3703 with P33XX insert
•
Use P3704 with P32XX insert
•
Call to specify material and finish
UNISTRUT
Concrete Inserts
End Cap
•
Call to specify material and finish
UNISTRUT
Concrete Inserts
Joint Covers
•
Use with Insert Series: P3270
*Note: Joint cover for use with 1-5/8”
wide standard Unistrut inserts only.
•
Call to specify material and finish
UNISTRUT
13/16” Series
P7000
•
Allowable Moment: 180 in-lbs
•
Call to specify material and finish
UNISTRUT
Channel Nut
P6006 With Spring
•
For Use with Channel P5500 only
•
Call to specify material and finish
UNISTRUT
Channel Nut
P7006 With Spring
•
For use with P7000
•
Call to specify material and finish
UNISTRUT
13/16” Series
P6026 2 Hole
•
Refer to Standard Dimensions for
width, thickness, hole diameters
and hole spacing
•
Call to specify material and finish
Item #
UTP3370X
Item #
UTP3712P
Item #
Channel
‘A’
UTP1704 P1000
2
¹³⁄₃₂
”
UTP3703 P3300
2
⁷⁄₁₆
”
UTP3704 P3000
3”
Item #
Fits Channel
UTP3280
P3000
UTP3380
P3300
Item #
UTP3663
Item #
UTP7000
Item #
Nut Size
UTP6006-0836 #8-36
UTP6006-0832 #8 -32
UTP6006-1032 #10-32
UTP6006-1024 #10-24
UTP6006-1420
¹⁄₄
”-20
Item #
Nut Size
UTP7006-1420
¹⁄₄
”-20
Item #
UTP6026
