Unistrut, Pipe Hangers & Caddy
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
UNISTRUT
Wing Shape Fitting
P 2346 8 Hole
•
Refer to Standard Dimensions for
width, thickness, hole diameters and
hole spacing
•
Call to specify material and finish
UNISTRUT
Post Base
P2942
•
Refer to Standard Dimensions for width,
thickness, hole diameters and hole spacing
•
Call to specify material and finish
UNISTRUT
Post Base
P2072XX
•
6” x 6” Square Base
•
Hole Diameter: 9/16” (14.3 mm)
•
Hole Spacing (From End): 13/16” (20.6
mm)
•
Hole Spacing (on Center): 1-7/8” (47.6
mm)
•
Width: 1-5/8” (41 mm)
•
Thickness: 1/4” (6.4 mm)
UNISTRUT
Poast Base
P2072AXX
•
6” x 6” Square Base
•
Hole Diameter: 9/16” (14.3 mm)
•
Hole Spacing (From End): 13/16” (20.6
mm)
•
Hole Spacing (on Center): 1-7/8” (47.6
mm)
•
Width: 1-5/8” (41 mm)
•
Thickness: 1/4” (6.4 mm)
UNISTRUT
Post Base
P2073A & P2073ASQ
SQ indicates opening square with
side of plate
•
Refer to Standard Dimensions
for width, thickness, hole
diameters and hole spacing
•
Call to specify material and finish
UNISTRUT
Brackets
P1771 Heavy Duty
•
Material: 1/4” (6.4) Thick Steel
•
Call to specify material and finish
UNISTRUT
Brackets
P1773 Heavy Duty
•
Material: 1/4” (6.4) Thick Steel
•
Call to specify material and finish
UNISTRUT
Brackets
P1775 Heavy Duty
•
Material: 1/4” (6.4) Thick Steel
•
Call to specify material and finish
UNISTRUT
Brackets
P1777 Heavy Duty
•
Material: 1/4” (6.4) Thick Steel
•
Call to specify material and finish
Item #
UTP2346
Item #
UTP2942
Item #
UTP2072
Item #
UTP2072A
Item #
UTP2073A
Square Base
UTP2073ASQ
Item #
UTP1771
Item #
UTP1773
Item #
UTP1775
Item #
UTP1777
