Unistrut, Pipe Hangers & Caddy
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
UNISTRUT
Pipe Straps
P2558-XX
•
Call to specify material and finish
UNISTRUT
Insulated Pipe Clamps
Cush-A-Clamp®
•
All tube series above 1
³⁄₄
” are furnished without the controlled-squeeze shoulder bolt; these sizes feature a
threaded stud securely fastened to one clamp half
•
Tube O.D. is Cushion I.D. All parts are marked for easy identification and packaged for small lot or bulk use
•
Call to specify material and finish
UNISTRUT
Tubing Clamps
One Hole Clamp
•
1/4” x 3/4” Round head machine
screw and Channel nut not
included
•
Call to specify material and finish
Item #
Nominal Pipe Size ‘A’ Size ‘B’ Size ‘C’ Size Thickness Design Load (lbs.)
UTP2558-05
¹⁄₂
”
2
⁷⁄₈
”
⁹⁄₃₂
”
⁷⁄₁₆
”
¹⁄₈
”
500
UTP2558-07
³⁄₄
”
3
¹⁄₈
”
⁹⁄₃₂
”
⁷⁄₁₆
”
¹⁄₈
”
500
UTP2558-10
1”
3
³⁄₈
”
⁹⁄₃₂
”
⁷⁄₁₆
”
¹⁄₈
”
500
UTP2558-12
1
¹⁄₄
”
3
³⁄₄
”
⁹⁄₃₂
”
⁷⁄₁₆
”
¹⁄₈
”
500
UTP2558-15
1
¹⁄₂
”
3
⁷⁄₈
”
⁹⁄₃₂
”
⁷⁄₁₆
”
¹⁄₈
”
500
UTP2558-20
2”
5
³⁄₄
”
⁷⁄₁₆
”
¹¹⁄₁₆
”
¹⁄₄
”
1,000
UTP2558-25
2
¹⁄₂
”
6
¹⁄₄
”
⁷⁄₁₆
”
¹¹⁄₁₆
”
¹⁄₄
”
1,000
UTP2558-30
3”
6
⁷⁄₈
”
⁷⁄₁₆
”
¹¹⁄₁₆
”
¹⁄₄
”
1,000
Item # Tubing O.D. Pipe Nom.
Dim A
Dim B
Dim C Dim D
Tube Series
UT010T014
⁵⁄₈
”
¹⁄₂
”
0.62”
1.06”
1.54”
0.46”
UT014T018
⁷⁄₈
”
³⁄₄
”
0.87”
1.31”
1.82”
0.58”
UT018T022
1
¹⁄₈
”
1”
1.12”
1.57”
2.08”
0.70”
UT024N028 1
¹⁄₂
”
1
¹⁄₄
”
1.50”
1.95”
2.47”
0.90”
UT026T030
1
⁵⁄₈
”
1
¹⁄₂
”
1.62”
2.07”
2.60”
0.96”
Pipe Series
UT017N022
-
³⁄₄
”
1.05”
1.50”
1.95”
0.70”
Item # O.D. Tube Size Thickness (ga.)
UTP2009
¹⁄₄
”
16
UTP2010
⁵⁄₁₆
”
16
UTP2020
1”
14
