ANVIL
Steel Pipe Clamps
Figure 103 Offset Pipe Clamp
•
Size Range: 3⁄4" through 8"
•
Material: Carbon steel
•
Finish: Plain or Galvanized
•
For use in supporting piping away from wall or floor
•
Maximum Temperature: Plain 650° F, Galvanized 450° F
•
Specify pipe size, figure number, name and finish
•
Not to be used as a riser type support
ANVIL
Steel Pipe Clamps
Figure 212FP Earthquake Bracing Clamp
•
Size Range:2-1⁄2" through 12"
•
Material: Carbon steel
•
Finish: Plain or Galvanized
•
For seismic bracing, to be used with Fig. 113 brace fitting. Pipe clamp bolt holes are designed to match holes
in brace fitting
•
Maximum Temperature: Plain 750° F, Galvanized 450° F
•
Complies with Federal Specification A-A-1192A (Type 4)
WW-H-171-E (Type 4), ANSI/MSS SP-69 and MSS SP-58 (Type 4)
•
Specify pipe size, figure number, name and finish
•
Note: The “C” gap dimension should be used at the upper and lower locations to ensure proper installation of the clamp
•
Standard Figure 212 will be furnished for sizes 2-1⁄2" thru 4"
Item # Pipe Size (in.) Max Load (lbs.) Weight (lbs.)
W (in.)
B (in.)
D (in.)
Bolt Dia. F (in.)
AV103-3/4
³⁄₄
190
1.50
8
³⁄₄
2
¹⁄₂
⁷⁄₁₆
³⁄₈
AV103-1
1
190
1.60
9
¹⁄₄
2
⁵⁄₈
⁷⁄₁₆
³⁄₈
AV103-1-1/4
1
¹⁄₄
190
1.70
9
³⁄₄
2
¹³⁄₁₆
⁷⁄₁₆
³⁄₈
AV103-1-1/2
1
¹⁄₂
190
1.80
10
2
¹⁵⁄₁₆
⁷⁄₁₆
³⁄₈
AV103-2
2
420
2.70
11
¹⁄₄
3
³⁄₁₆
⁹⁄₁₆
¹⁄₂
AV103-2-1/2
2
¹⁄₂
420
2.90
11
³⁄₄
3
⁷⁄₁₆
⁹⁄₁₆
¹⁄₂
AV103-3
3
420
3.20
12
⁷⁄₈
3
³⁄₄
⁹⁄₁₆
¹⁄₂
AV103-4
4
610
4.60
13
⁷⁄₈
4
¹⁄₄
⁹⁄₁₆
¹⁄₂
AV103-5
5
610
7.30
15
⁵⁄₈
4
³⁄₄
1
¹⁄₁₆
⁵⁄₈
AV103-6
6
870
7.80
16
³⁄₄
5
⁵⁄₁₆
1
¹⁄₁₆
⁵⁄₈
AV103-8
8
870
9.00
18
³⁄₄
6
⁵⁄₁₆
1
¹⁄₁₆
⁵⁄₈
Item #
Pipe
Size (in.)
Max Load For
Service Temp 650°
Max Load For
Service Temp 750°
Weigh
t (lbs.) B (in.) C (in.)
Rod Take
Out E (in.) H (in.) D (in.) F (in.)
AV212FP-2-1/2 2
¹⁄₂
1,040
930
1.20 2
⁵⁄₈
⁵⁄₈
2
⁵⁄₈
3
¹⁄₄
3
¹⁄₄
¹⁄₂
AV212FP-3
3
1,040
930
1.40 2
⁷⁄₈
⁵⁄₈
2
⁷⁄₈
3
¹⁄₂
3
¹⁄₂
¹⁄₂
AV212FP-3-1/2 3
¹⁄₂
1,040
930
1.50 3
³⁄₁₆
⁵⁄₈
3
³⁄₁₆
3
¹³⁄₁₆
3
¹³⁄₁₆
¹⁄₂
AV212FP-4
4
1,040
930
1.80 3
¹⁄₂
⁵⁄₈
3
¹⁄₂
4
¹⁄₄
4
¹⁄₄
¹⁄₂
AV212FP-5
5
1,040
930
2.50 4
³⁄₁₆
³⁄₄
4
³⁄₁₆
4
¹⁵⁄₁₆
4
¹⁵⁄₁₆
¹⁄₂
AV212FP-6
6
1,040
930
5.20 4
⁷⁄₈
1
¹⁄₄
4
⁷⁄₈
5
³⁄₄
5
³⁄₄
¹⁄₂
AV212FP-8
8
1,040
930
6.30 6
1
¹⁄₄
6
6
⁷⁄₈
6
⁷⁄₈
¹⁄₂
AV212FP-10
10
1,040
930
13.60 7
⁷⁄₁₆
1
7
⁷⁄₁₆
8
⁹⁄₁₆
8
⁹⁄₁₆
¹⁄₂
AV212FP-12
12
1,040
930
15.20 8
⁷⁄₁₆
1
8
⁷⁄₁₆
9
⁹⁄₁₆
9
⁹⁄₁₆
¹⁄₂
