ANVIL
Straps
Figure 262 Short strap
•
Size Range: 1⁄2" through 4"
•
Material: Carbon steel
•
Finish: Plain or Galvanized
•
Maximum Temperature: 650° F
•
Complies with Federal Specification A-A-1192A (Type 26), WW-H-171-E (Type 26), ANSI/MSS SP-69 and MSS SP-58 (Type 26)
•
Specify pipe size, figure number, name and finish
•
Note: The acceptability of galvanized coatings at temperatures above 450°F is at the discretion of the end user
Item #
Pipe
Size (in.)
Max Load
(w/Lag
Screws / w/
Bolts to
Steel) (lbs.)
Weight
(lbs.)
Screw or Bolt Size L (in.) B (in.) C (in.) D (in.) E (in.) F (in.)
AV262-1/2
¹⁄₂
300/410 0.20 Two #18x2 Steel Wood
Screws or Two
³⁄₈
” Bolts
To Steel
4
1
¹⁄₄
2
³⁄₄
¹⁄₂
1
¹⁄₈
¹⁄₈
AV262-3/4
³⁄₄
300/410 0.23 Two #18x2 Steel Wood
Screws or Two
³⁄₈
” Bolts
To Steel
4
³⁄₈
1
¹⁄₄
3
¹⁄₈
¹¹⁄₁₆
1
⁷⁄₁₆
¹⁄₈
AV262-1
1
300/410 0.26 Two #18x2 Steel Wood
Screws or Two
³⁄₈
” Bolts
To Steel
4
³⁄₄
1
¹⁄₄
3
¹⁄₂
¹¹⁄₁₆
1
⁵⁄₈
¹⁄₈
AV262-1-1/4 1
¹⁄₄
300/410 0.36 Two #18x2 Steel Wood
Screws or Two
³⁄₈
” Bolts
To Steel
5
1
¹⁄₄
3
³⁄₄
1
¹⁄₁₆
2
¹⁄₈
¹⁄₈
AV262-1-1/2 1
¹⁄₂
300/410 0.54 Two #18x2 Steel Wood
Screws or Two
³⁄₈
” Bolts
To Steel
5
³⁄₈
1
¹⁄₄
4
¹⁄₈
1
³⁄₈
2
¹⁄₂
¹⁄₈
AV262-2
2
300/410 0.60 Two #18x2 Steel Wood
Screws or Two
³⁄₈
” Bolts
To Steel
6
³⁄₈
1
¹⁄₄
5
¹⁄₈
1
¹⁄₄
2
³⁄₄
¹⁄₈
AV262-2-1/
2
2
¹⁄₂
450/610 1.40 Two #18x Steel Wood
Screws or Two
³⁄₈
” Bolts
To Steel
6
¹³⁄₁₆
1
¹⁄₂
5
⁹⁄₁₆
1
³⁄₄
3
⁵⁄₈
¹⁄₄
AV262-3
3
450/610 1.60 Two #18x Steel Wood
Screws or Two
³⁄₈
” Bolts
To Steel
7
⁵⁄₁₆
1
¹⁄₂
6
¹⁄₁₆
1
⁷⁄₈
4
¹⁄₄
AV262-3-1/
2
3
¹⁄₂
450/610 1.80 Two #18x Steel Wood
Screws or Two
³⁄₈
” Bolts
To Steel
7
¹³⁄₁₆
1
¹⁄₂
6
⁹⁄₁₆
2
³⁄₁₆
4
⁵⁄₈
¹⁄₄
AV262-4
4
450/610 1.90 Two #18x Steel Wood
Screws or Two
³⁄₈
” Bolts
To Steel
8
³⁄₈
1
¹⁄₂
7
¹⁄₈
2
³⁄₈
5
¹⁄₄
