ANVIL
Pipe Supports
Figure 265 Adjustable Pipe Saddle Support
•
Size Range: 4" through 36"
•
Material: Cast iron saddle, steel yoke and nuts, steel locknut nipple and special cast iron reducer. (14" through 36" carbon
steel saddle with steel yoke. 4" through 12" steel saddle available upon special request)
•
Finish: Plain or Galvanized
•
Stanchion type support where vertical adjustment is required, plus the additional stability provided by U-bolt attachment to
pipe
•
Complies with Federal Specification A-A-1192A (Type 38),
WW-H-171-E (Type 39), ANSI/MSS SP-69 and MSS SP-58
•
Installation: Adjustment is obtained by turning the locknut nipple. The lower end of the nipple is staked, upsetting the
threads to prevent
separation of nipple and coupling during adjustment
•
Features: Vertical adjustment of approximately 4-1⁄2"
•
Saddle supports a broad range of pipe sizes
•
Specify pipe size to be supported, figure number, name and finish
ERICO/CADDY
One-Piece Strut Clamps
ERICO/CADDY
Conduit Clips
Item #
Pipe
Size (in.)
Weight
Complete (lbs.)
Weight Saddle
Only (lbs.)
A (in.)
B (in.)
D (in.) E Min. (in.)
E Max.
(in.)
Width C
(in.)
Max Load
(lbs.)
AV265-4
4
22.0
10.8
4
4
³⁄₁₆
3
9
¹⁄₂
14
3
⁵⁄₈
3,800
AV265-5
5
23.1
12.1
4
4
¹³⁄₁₆
3
10
¹⁄₈
14
⁵⁄₈
3
⁵⁄₈
3,800
AV265-6
6
23.9
12.7
4
5
⁷⁄₁₆
3
10
³⁄₄
15
¹⁄₄
3
⁵⁄₈
3,800
AV265-8
8
32.5
21.3
4
6
¹⁵⁄₁₆
3
12
¹⁄₄
16
³⁄₄
3
⁵⁄₈
3,800
AV265-10 10
36.9
25.7
4
8
⁷⁄₁₆
3
13
³⁄₄
18
¹⁄₄
3
⁵⁄₈
3,800
AV265-12 12
42.4
31.2
4
9
¹⁵⁄₁₆
3
14
⁵⁄₈
19
¹⁄₈
3
⁵⁄₈
3,800
AV265-14 14
39.2
28.0
4
10
¹⁄₂
3
15
¹³⁄₁₆
20
⁵⁄₁₆
6
5,300
AV265-16 16
42.2
31.0
4
11
¹⁄₂
3
16
¹³⁄₁₆
21
⁵⁄₁₆
6
5,300
AV265-18 18
60.0
40.0
6
13
¹⁄₂
3
¹⁄₂
19
¹⁄₈
23
⁵⁄₈
6
6,700
AV265-20 20
63.0
43.0
6
14
¹⁄₂
3
¹⁄₂
20
¹⁄₈
24
⁵⁄₈
6
6,700
AV265-22 22
66.0
46.0
6
15
¹⁄₂
4
21
⁵⁄₁₆
25
¹³⁄₁₆
6
7,300
AV265-24 24
72.0
52.0
6
17
¹⁄₂
4
23
⁵⁄₁₆
27
¹³⁄₁₆
6
7,300
AV265-26 26
75.0
57.0
6
18
¹⁄₂
4
24
⁵⁄₁₆
28
¹³⁄₁₆
6
7,300
AV265-30 30
89.0
69.0
6
20
⁵⁄₈
4
26
⁷⁄₁₆
30
¹⁵⁄₁₆
6
7,300
AV265-32 32
93.0
73.0
6
21
⁵⁄₈
4
27
⁷⁄₁₆
31
¹⁵⁄₁₆
6
7,300
AV265-36 36
101.0
81.0
6
23
⁵⁄₈
4
29
⁷⁄₁₆
33
¹⁵⁄₁₆
6
7,300
Item # Size (in.) Rigid (in.)
Load
(lbs.)
CASCH8
¹⁄₂
200
CASCH12
³⁄₄
¹⁄₂
200
CASCH16
1
³⁄₄
200
CASCH20 1
¹⁄₄
1
200
CASCH12B
³⁄₄
¹⁄₂
200
Item #
Conduit Size
Mounting Hole
(in.)
CA6M For 6M 14-2 thru 12-3 MC/AC
and
³⁄₈
” Flexible Conduit
⁹⁄₃₂
Plain
CA812M4I
¹⁄₂
” to
³⁄₄
”
¹⁄₄
- 20 Thread
Impression
