539
LINDAPTER®
TYPE P1 SHORT /
P2 SHORT
Steel Clamp Accessories
•
Packing used to adjust the tail
length of the clamp to meet differing beam flange thicknesses
•
Mild steel, malleable iron; Bright zinc or hot dip galvanized finish
•
For use with Type A or B Clamps
•
Contact Edge for detailed specs and design data
LINDAPTER®
TYPE T
Steel Clamp Accessory
•
To fill the nose of Type A and B, making it
horizontal
•
For parallel flanges only
•
Thickness ‘T’ should be added for tail length and
bolt length calculations
•
Product is for aesthetic purposes only and
technically not necessary
•
Malleable iron; Bright zinc plated or hot dip
galvanized finish
•
Contact Edge for detailed specs and design data
LINDAPTER®
TYPE W
Steel Clamp Accessory
•
Washer to fill the recess of Type A to enable the
nut to be tightened
•
Mild Steel, malleable iron; Bright zinc plated or
hot dip galvanized finish
•
Contact Edge for detailed specs and design data
LINDAPTER®
Type CF
High Friction Steel Clamp
•
High friction clamp which hooks over flanges of beams, angles and channels
•
Lindapter markings act as a unique anti-rotation device
•
Can be combined with all Lindapter Girder Clamp products including Type AF
•
SG iron; Hot dip galvanized finish
•
Contact Edge for detailed specs and design data
•
Ask about adjusted safe working loads when using Type CF clamps in conjunction with other Lindapter clamps (Type A & Type AF)
Item # Bolt Size Z Y X T Width
P1
LDLP1037S
³⁄₈
”
³⁄₁₆
”
¹⁄₂
”
³⁄₁₆
”
¹⁵⁄₁₆
”
LDLP1050S
¹⁄₂
”
¹⁄₄
”
⁵⁄₈
”
¹⁄₄
”
1
³⁄₁₆
”
LDLP1062S
⁵⁄₈
”
⁵⁄₁₆
”
¹³⁄₁₆
”
⁵⁄₁₆
”
1
³⁄₈
”
LDLP1075S
³⁄₄
”
³⁄₈
”
¹⁵⁄₁₆
”
³⁄₈
” 1
¹¹⁄₁₆
”
LDLP1100S 1”
¹⁄₂
”
1
¹⁄₄
”
¹⁄₂
”
2
¹⁄₈
”
P2
LDLP2037S
³⁄₈
”
³⁄₁₆
”
¹⁄₂
”
³⁄₈
”
¹⁵⁄₁₆
”
LDLP2050S
¹⁄₂
”
¹⁄₄
”
⁵⁄₈
”
¹⁄₂
”
1
³⁄₁₆
”
LDLP2062S
⁵⁄₈
”
⁵⁄₁₆
”
¹³⁄₁₆
”
⁵⁄₈
”
1
³⁄₈
”
LDLP2075S
³⁄₄
”
³⁄₈
”
¹⁵⁄₁₆
”
³⁄₄
” 1
¹¹⁄₁₆
”
LDLP2100S 1”
¹⁄₂
”
1
¹⁄₄
”
1”
2
¹⁄₈
”
Item # Bolt Size Z Dimensions T
LDLT050
¹⁄₂
”
¹⁄₈
”
LDLT062
⁵⁄₈
”
³⁄₁₆
”
LDLT072
³⁄₄
”
³⁄₁₆
”
LDLT100
1”
¹⁄₄
”
Item # Bolt Size Z Dimensions T
LDLW037
³⁄₈
”
³⁄₁₆
”
LDLW050
¹⁄₂
”
¹⁄₄
”
LDLW062
⁵⁄₈
”
⁵⁄₁₆
”
LDLW075
³⁄₄
”
³⁄₈
”
Item #
Bolt
Grade 5
Safe Working Loads
(5:1 Factor Of Safety)
Tensile/1 Bolt (lbs.)
Safe Working Loads
(2:1 Factor Of Safety)
Frictional/2 Bolts Painted Steel (lbs.)
Safe Working Loads
(2:1 Factor Of Safety)
Frictional/2 Bolts Galvanized Steel (lbs.)
Torque
(ft./lbs.)
LDLCF050
¹⁄₂
”
1,911
764
877
66
LDLCF062
⁵⁄₈
”
3,597
1,798
2,248
177
LDLCF075
³⁄₄
”
5,901
2,922
3,597
347
