Lindapter-Structural Fastening
545
Boise, ID 208-377-0158
Eugene, OR 541-342-3641
Idaho Falls, ID 208-522-7082
Medford, OR 541-779-0187
LINDAPTER®
TYPE SW-Swivel Unit
Pipe / Conduit Support
•
Swivel unit for applications on inclined beams
•
Can be used with Type FL
•
Supplied complete with grade 8.8 M10 x 1-9/16" setscrew and nut
•
High grade alloy steel
•
Bright zinc plated finish
•
Contact Edge for detailed specs and design data
LINDAPTER®
TYPE F3
Pipe/Conduit Support
•
Two part flange clamp with large clamping range
•
Bolt can be substituted with either threaded rod or hook bolts
•
For parallel flanges only
•
Malleable iron
•
Hot dip galvanized finish
•
WB represents product with bolt
•
NB represents product without bolt
•
Contact Edge for detailed specs and design data
LINDAPTER®
TYPE FF
Floorfast®
•
To hold down diamond plate flooring
•
Consists of a malleable iron body casting with a countersunk socket screw. The eccentric stepped
web of the casting allows it to lock under the steel, providing full face contact when torque is applied
•
For thicker flanges, packing pieces can be supplied
•
Lloyds’ Register Type Approval for vibration resistance
•
Malleable iron; Bright zinc plated or hot dip galvanized finish
•
Also available in stainless steel grade 316
•
Contact Edge for detailed specs and design data
Item # Drop Rod
Safe Working Load
(4:1 Factor of Safety)
Tensile lbs.
Max Inclination Rotation
Torque
(ft.lb.)
Dimensions
U
Dimensions
R
Dimensions With
Bolt Width V
LDLSW037 M10 (
³⁄₈
”)
540
18°
360°
8
1
³⁄₄
”
1”
1
³⁄₈
”
Item #
Bolt
Thread Z
Safe Working Load
(4:1 Factor of Safety)
Tensile/1 Bolt (lbs.)
Clamping
Thickness W
(Min-Max)
Torque
(ft.lb).
Dimensions
S
Dimensions
T
Dimensions
V
Dimensions
X
Width
R
With Bolt
LDLF3037WB M10
270
¹⁄₁₆
”-1
³⁄₁₆
”
15
⁷⁄₈
”
⁵⁄₁₆
”
³⁄₈
”
1”
1
¹⁄₂
”
LDLF3050WB M12
450
³⁄₃₂
”-1
⁹⁄₁₆
”
29
1
¹⁄₈
”
³⁄₈
”
¹⁄₂
”
1
³⁄₈
”
1
¹⁵⁄₁₆
”
LDLF3062WB M16
900
³⁄₃₂
”-2
³⁄₁₆
”
69
1
³⁄₈
”
¹⁄₂
”
⁵⁄₈
”
1
¹³⁄₁₆
”
2
³⁄₈
”
LDLF3075WB M20
1,350
⁵⁄₃₂
”-2
³⁄₄
”
130
1
³⁄₄
”
⁹⁄₁₆
”
³⁄₄
”
2
³⁄₁₆
”
3”
No Bolt
LDLF3037NB M10
270
¹⁄₁₆
”-1
³⁄₁₆
”
15
⁷⁄₈
”
⁵⁄₁₆
”
³⁄₈
”
1”
1
¹⁄₂
”
LDLF3050NB M12
450
³⁄₃₂
”-1
⁹⁄₁₆
”
29
1
¹⁄₈
”
³⁄₈
”
¹⁄₂
”
1
³⁄₈
”
1
¹⁵⁄₁₆
”
LDLF3062NB M16
900
³⁄₃₂
”-2
³⁄₁₆
”
69
1
³⁄₈
”
¹⁄₂
”
⁵⁄₈
”
1
¹³⁄₁₆
”
2
³⁄₈
”
LDLF3075NB M20
1,350
⁵⁄₃₂
”-2
³⁄₄
”
130
1
³⁄₄
”
⁹⁄₁₆
”
³⁄₄
”
2
³⁄₁₆
”
3”
Item #
Bolt Z Floorplate Thickness t
Flange Thickness
LDLFF031
M8
¹⁄₈
”-
¹⁄₂
”
¹⁄₈
”-
⁵⁄₈
”
LDLFF037
M10
³⁄₁₆
”-
¹⁄₂
”
¹⁄₈
”-
⁵⁄₈
”
LDLFF050
M12
¹⁄₄
”-
¹⁄₂
”
¹⁄₈
”-
⁵⁄₈
”
