SIMPSON STRONG-TIE®
Injection Epoxy
ETI
ETI injection epoxies are specially designed formulations for the injection of cracks in concrete. ETI epoxies are two-component,
1:1 ratio, high solids formulations. They are available in 22 ounce side-by-side cartridges and are dispensed through a static
mixing nozzle using a manual,
battery or pneumatic dispensing tool. ETI is available in two viscosities: ETI-LV (low viscosity) and ETI-GV (gel viscosity) to
handle a wide range of crack widths. Properly installed, they provide a repair that is both waterproof and
high strength (structural).
ETI-LV Low Viscosity Injection Epoxy:
•
Low viscosity epoxy (1790 cps) for repair of fine to medium width cracks ¼⁄" - ¼⁄" in width
•
Low surface tension allows the material to effectively penetrate narrow cracks
•
Suitable for structural repairs
ETI-GV Gel Viscosity Injection Epoxy
•
Gel viscosity epoxy for repair of medium cracks 3/32" - 1/4" in width
•
Decreases in viscosity under pressure for increased fl owability
•
Suitable for structural repairs
APPLICATION: Epoxy-Tie® injection epoxies are suitable for repairing non-moving cracks in concrete walls, floors, slabs, columns and beams.
They can be used to inject cracks in damp or wet conditions with excellent results. Apply to concrete 40°F or above. For best results, warm
material to 60°F or above prior to application
•
SHELF LIFE: 2 years in unopened cartridge
SIMPSON STRONG-TIE®
High Strength Acrylic-Tie® Anchoring Adhesive
AT-XP™
Acrylic-Tie® AT-XP™ anchoring adhesive is specifically formulated for fast curing and delivers optimum
performance anchoring threaded rod and dowels in uncracked concrete
•
AT-XP adhesive blends high strength with EASY COLD WEATHER DISPENSING and excellent
reduced-temperature performance to provide a complete adhesive anchoring solution
•
Rigorously tested in accordance with ICC-ES AC308 and IBC 2009 requirements for uncracked concrete,
reduced-temperature testing results have shown AT-XP adhesive to dispense easily with no load reductions
in substrate temperatures as low as 14°F (-10°C)
•
AT–XP is a two-component, high-solids, 10:1 ratio acrylic-based adhesive for use as a high strength,
anchor-grouting material. Resin and initiator are dispensed and mixed simultaneously through the mixing
nozzle
•
USES: Threaded rod anchoring in concrete, rebar doweling in concrete
•
SHELF LIFE: Nine months from date of manufacture in unopened cartridge
•
Cure Schedule (Base Material Temp° / Cure Time hrs.): 14/24, 32/8, 50/3, 68/1
•
APPROVED BY IAPMO
Item # Capacity (oz.) Cartridge Type Ctn Qty.
Dispensing Tool(s)
Mixing Nozzle
SNETILV22
22
Side-by Side 10 EDT22B,EDT22AP,EDT22CKT EMN022 (Included)
SNETIGV22
22
Side-by Side 10 EDT22B,EDT22AP,EDT22CKT EMN022 (Included)
Item # Capacity (oz.) Cartridge Type Carton Qty
Dispensing Tool(s)
Mixing Nozzle
SNAT-XP13
13
Side-by-Side
10
ADT813S
AMN19Q
SNAT-XP30
30
Side-by-Side
5
ADT30S, ADT30P, ADT30CKT
AMN19Q
SNAT-XP10
10
Coaxial
12
CDT10S
AMN19Q
