557
SIMPSON STRONG-TIE®
Screw Anchor for Concrete and
Masonry
TITEN HD® MINI Screw Anchor
•
Sharing the same features as the larger Titen
HD® screw anchor (page 119), the Titen HD®
Minianchor provides an easy solution for jobs that
call for smaller anchors
•
The self-undercutting, non-expansion
characteristics are ideal for situations where
minimum edge distance and reduced spacing is a
concern. The patented cutting teeth and thread design enable the
Titen HD Mini anchor to be installed quickly and with less effort
than many other screw type anchors
•
Since there are no secondary setting steps involved, the Titen HD
Mini screw anchor can be installed much more quickly than tradi-
tional expansion anchors
•
FINISH: Zinc plated
•
TEST CRITERIA: The Titen HD® Mini anchor has been tested in
accordance with ASTM E488 standard test methods
for tension and shear.
SIMPSON STRONG-TIE®
Sleeve Anchors
SLEEVE-ALL®
•
Sleeve-Alls are pre-assembled expanding sleeve anchors for use in all types of hollow and solid base materials
•
These anchors are available in acorn, hex, rod coupler, flat or round head styles for a wide range of applications
Material: Carbon steel.
Finish: Zinc plated.
Code Approvals: Factory Mutual 3017082, 3026805 and 3029959, 3/8"-3/4” dia.; Underwriters Laboratories File Ex3605, 3/8”-3/4” dia.
Meets requirements of Federal Specifications A-A-1922A. The load tables list values based upon results from the most recent testing
and may not reflect those in the current code reports. Where code jurisdictions apply, consult the current reports for applicable load
values
Item #
Size ( in.)
Drill Bit
Dia. (in.)
Wrench
Size (in.) Box Qty.
SNTHD25134H
¹⁄₄
X1
³⁄₄
¹⁄₄
³⁄₈
100
SNTHD25214H
¹⁄₄
X2
¹⁄₄
¹⁄₄
³⁄₈
50
SNTHD25300H
¹⁄₄
X3
¹⁄₄
³⁄₈
50
SNTHD37134H
³⁄₈
X1
³⁄₄
³⁄₈
⁹⁄₁₆
50
SNTHD37212H
³⁄₈
X2
¹⁄₂
³⁄₈
⁹⁄₁₆
50
Item #
Part #
Size (in.) Bolt Dia. Thread (per in.) Max Material Thickness (in.) Quantity Box
Acorn Head
SNSL25214A
SL25214A
¹⁄₄
x 2
¹⁄₄
³⁄₁₆
-24
1
¹⁄₈
100
Hex Head
SNSL31212H
SL31212H
⁵⁄₁₆
x 2
¹⁄₂
¹⁄₄
-20
1
¹⁄₁₆
50
SNSL37300H
SL37178H
³⁄₈
x 1
⁷⁄₈
⁵⁄₁₆
-18
³⁄₈
50
SNSL37300H
SL37300H
³⁄₈
x 3
⁵⁄₁₆
-18
1
¹⁄₂
50
SNSL37400H
SL37400H
³⁄₈
x 4
⁵⁄₁₆
-18
2
¹⁄₂
50
SNSL50300H
SL50300H
¹⁄₂
x 3
³⁄₈
-16
³⁄₄
25
SNSL50400H
SL50400H
¹⁄₂
x 4
³⁄₈
-16
1
³⁄₄
25
SNSL50600H
SL50600H
¹⁄₂
x 6
³⁄₈
-16
3
³⁄₈
20
SNSL62414H
SL62414H
⁵⁄₈
x 4
¹⁄₄
¹⁄₂
-13
1
¹⁄₂
10
SNSL62600H
SL62600H
⁵⁄₈
x 6
¹⁄₂
-13
3
¹⁄₄
10
SNSL75414H
SL75414H
³⁄₄
x 4
¹⁄₄
⁵⁄₈
-11
⁷⁄₈
10
SNSL75614H
SL75614H
³⁄₄
x 6
¹⁄₄
⁵⁄₈
-11
2
⁷⁄₈
5
Flat Head
SNSL25200PF
SL25200PF
¹⁄₄
x 2
³⁄₁₆
-24
⁷⁄₈
100
SNSL25300PF
SL25300PF
¹⁄₄
x 3
³⁄₁₆
-24
1
⁷⁄₈
50
SNSL31312PF
SL31312PF
⁵⁄₁₆
x 3
¹⁄₂
¹⁄₄
-20
2
¹⁄₁₆
50
SNSL37234PF
SL37234PF
³⁄₈
x 2
³⁄₄
⁵⁄₁₆
-18
1
¹⁄₄
50
SNSL37400PF
SL37400PF
³⁄₈
x 4
⁵⁄₁₆
-18
2
¹⁄₂
50
SNSL37600PF
SL37600PF
³⁄₈
x 6
⁵⁄₁₆
-18
4
¹⁄₂
50
Round Head
SNSL25200R
SL25200R
¹⁄₄
x 2
³⁄₁₆
-24
⁷⁄₈
100
SNSL37212R
SL37212R
³⁄₈
x 2
¹⁄₂
⁵⁄₁₆
-18
1
50
