Anchors & Fastener Systems
551
Boise, ID 208-377-0158
Eugene, OR 541-342-3641
Idaho Falls, ID 208-522-7082
Medford, OR 541-779-0187
SIMPSON STRONG-TIE®
High Strength Epoxy-Tie Anchor System
SET-XP®
SET-XP®, the popular epoxy-based anchoring adhesive formulated for optimum performance in both cracked and uncracked
concrete, is now available in a 56 oz. cartridge for larger-volume jobs. Rigorously tested in accordance with ICC-ES AC308 2006
and 2009 IBC requirements, and proven to deliver increased reliability in the most adverse conditions, SET-XP provides greater
convenience coupled with unmatched performance. This non-shrink epoxy anchoring adhesive meets the requirements of
ASTM C881 specification for Type I and Type IV, Grade 3, Class C epoxy.
•
Uses: When SET-XP® adhesive is used with threaded rod, rebar or the IXP™ anchor, the system can be used in tension and
seismic zones where there is a risk of cracks occurring that pass through the anchor location. It is also suitable for uncracked
concrete conditions
•
Codes: ICC-ES ESR-2508; City of L.A. RR25744; Florida FL 11506.5 NSF/ANSI Standard 61 (216 in ⁄ gal).
•
Shelf life: 24 months from date of manufacture in unopened side-by-side cartridge
•
Cure Schedule (Base Material Temp° / Cure Time hrs.): 50/72, 70/24, 90/24, 110/24
SIMPSON STRONG-TIE®
Epoxy Anchor Cartridge
High Strength
SET
•
Epoxy-Tie SET epoxy is a two-component, low odor, 1:1 ratio, 100% solids epoxy-based adhesive for use as
a high strength, non-shrink anchor grouting material
•
Resin and hardener are dispensed and mixed simultaneously through the mixing nozzle. SET meets or
exceeds the ASTM C-881
specification for Type I, II, IV and V, Grade 3, Class B and C
•
USES: Threaded rod anchoring, Rebar dowelling, Bonding hardened concrete to hardened concrete, Pick proof sealant around doors,
windows and fixtures, Paste-over for crack injection
•
Code Approvals: ICC-ES ESR-1772 (CMU & URM); City of L.A. RR25279; Florida FL 11506.4; Caltrans approved; multiple DOT listings;
NSF/ANSI Standard 61 (216 in2/1000 gal), except SET1.7KTA. SET-PAC-EZ™ adhesive covered by ICC-ES, City of L.A. and NSF/ANSI
listings only
•
SHELF LIFE: 24 months from date of manufacture in unopened side-by-side cartridge. SET-PAC-EZ™ cartridge - 24 months from date of
manufacture, unopened
SIMPSON STRONG-TIE®
Epoxy-Tie® Adhesive Dispensing Tool
•
Each tool has been designed to work with Epoxy-Tie®
cartridges for trouble-free dispensing
•
These tools are for use with SET, SET-XP™, EDOT™, ET, ETI adhesives and CIP and CIP-F paste-over material
Item # Capacity (oz.) Cartridge Type Ctn Qty.
Dispensing Tool(s)
Mixing Nozzle
SNSET-XP22
22
Side-by-Side
10
EDT22B, EDT22AP, EDT22CKT, EDT22S EMN22i
SNSET-XP56
56
Side-by-Side
56
EDT56AP
EMN22i
Item #
Capacity (oz.) Cartridge Type Carton Qty
Dispensing Tool(s)
Mixing Nozzle UoM
SNSET1.7KTA
1.7
Side-by Side
12
Adapter Included for Standard Caulking Tool
EMN1.7 (2
included)
Ea
SNSET-PAC-EZ
8.5
Single
12
CDT10 or High Quality Standard Caulking Tool
2 Included
SNSET22
22
Side-by Side
12
CDT10 or High Quality Standard Caulking Tool
EMN22i
Ea
SNSET56
56
Side-by Side
6
EDT56AP
EMN22i, EMN50 Ea
Item #
Description
SNCDT10
Premium Tool for Single Cartridges
SNEDT22B
Manual Tool for 22 oz. Cartridges
SNEDT22CKT
Battery Powered Tool for 220 oz. Cartridges
SNEDT22AP
Pneumatic Tool for 22 oz. Cartridges
SNEDT56AP
Pneumatic Tool for 56 oz. Cartridges
SNEDT22S Manual Tool for twin 300 ml Cartridges or 300/150 ml Cartridges
