LINDAPTER®
Type GF
Grate-Fast®
•
Grating connection for rectangular open bar grating
•
LGF031 with stainless steel top-hat bracket for GRP grating
•
LGF037(OSB) with wider top-hat bracket for different grating sizes
•
LGF037 for use with 1-3/16” width floor grating bars only
•
Body: Malleable iron, mechanical galvanized or hot dip galvanized finish
•
Top Hat: Mild steel, mechanical galvanized or hot dip galvanized finish
•
Lloyds’ Register type Approval for vibration resistance
•
Contact Edge for detailed specs and design data
Item #
Bolt Z Flange T Grating Bar Depth D Grating Bar Width W Bar Distance X Body Width (in.) Torque (ft./lbs.)
LDLGF031
M8
¹⁄₈
”-
³⁄₄
”
⁷⁄₈
”-1
¹⁄₂
”
³⁄₁₆
”-
³⁄₈
”
³⁄₄
”-1
⁷⁄₈
”
⁵⁄₈
”
4
LDLGF037(OSB) M10
¹⁄₈
”-
³⁄₄
”
¹³⁄₁₆
”-1
³⁄₁₆
”
¹⁄₈
”-
¹⁄₄
”
1”-1
³⁄₄
”
³⁄₄
”
8
LDLGF037 M10
¹⁄₈
”-
³⁄₄
”
³⁄₄
”-1
¹⁄₄
”
¹⁄₈
”-
¹⁄₄
”
1
³⁄₁₆
”
³⁄₄
”
8
