Anchors & Fastener Systems
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
ITW REDHEAD
Wedge Anchors
Type 304 Stainless Steel
Trubolt®
Typical applications-Cladding, stadium seating, etc.
Serves many applications well. It withstands rusting in architectural and food processing environments and resists organic chemicals,
dye stuffs and many inorganic chemicals.
ITW REDHEAD
Drop-In Anchors
Lipped
RM Series
•
For solid concrete, lightweight fill deck
•
Lipped anchor body keeps anchor flush
Item #
Thread Length
in. (mm)
Anchor Dia. & Drill Bit
Size (Threads) Per (in.)
Overall Length
in. (mm)
Max. Thickness of Material
to be Fastened in. (mm)
Qty/Wt per Box (lbs.)
RAWW-1416
³⁄₄
(19.1)
¹⁄₄
- 20
1
³⁄₄
(44.5)
³⁄₈
(9.5)
100/3.2
RAWW-1422 1
¹⁄₄
(31.8)
¹⁄₄
- 20
2
¹⁄₄
(57.2)
⁷⁄₈
(22.2)
100/3.7
RAWW-1432 2
¹⁄₄
(57.2)
¹⁄₄
- 20
3
¹⁄₄
(82.6)
1
⁷⁄₈
(47.6)
100/4.8
RAWW-3822 1
¹⁄₈
(28.6)
³⁄₈
- 16
2
¹⁄₄
(57.2)
³⁄₈
(9.5)
50/4.1
RAWW-3826 1
⁵⁄₈
(41.3)
³⁄₈
- 16
2
³⁄₄
(69.9)
⁷⁄₈
(22.2)
50/4.8
RAWW-3830 1
⁷⁄₈
(47.6)
³⁄₈
- 16
3 (76.2)
1
¹⁄₈
(28.6)
50/5.1
RAWW-3836 2
⁵⁄₈
(66.7)
³⁄₈
- 16
3
³⁄₄
(95.3)
1
⁷⁄₈
(47.6)
50/6.0
RAWW-3850 2
³⁄₄
(69.9)
³⁄₈
- 16
5 (127.0)
3
¹⁄₈
(79.4)
50/7.5
RAWW-1226 1
¹⁄₄
(31.8)
¹⁄₂
- 13
2
³⁄₄
(69.9)
¹⁄₈
(3.2)
25/4.7
RAWW-1236 2
¹⁄₄
(57.2)
¹⁄₂
- 13
3
³⁄₄
(95.3)
1 (25.4)
25/5.8
RAWW-1242 2
³⁄₄
(69.9)
¹⁄₂
- 13
4
¹⁄₄
(108.0)
1
¹⁄₂
(38.1)
25/6.3
RAWW-1254
3 (76.2)
¹⁄₂
- 13
5
¹⁄₂
(139.7)
2
³⁄₄
(69.9)
25/7.7
RAWW-1270 3
¹⁄₂
(88.9)
¹⁄₂
- 13
7 (177.8)
4
¹⁄₄
(108.0)
25/9.4
RAWW-5834 1
³⁄₄
(44.5)
⁵⁄₈
- 11
3
¹⁄₂
(88.9)
¹⁄₈
(3.2)
10/3.6
RAWW-5850 3
¹⁄₄
(82.6)
⁵⁄₈
- 11
5 (127.0)
1
⁵⁄₈
(41.3)
10/4.8
RAWW-5860 3
¹⁄₂
(88.9)
⁵⁄₈
- 11
6 (152.4)
2
⁵⁄₈
(66.7)
10/5.5
RAWW-5870 3
¹⁄₂
(88.9)
⁵⁄₈
- 11
7 (117.8)
3
⁵⁄₈
(92.1)
10/6.2
RAWW-3446 2
¹⁄₄
(57.2)
³⁄₄
- 10
4
³⁄₄
(120.7)
³⁄₄
(19.1)
10/6.7
RAWW-3454
3 (76.2)
³⁄₄
- 10
5
¹⁄₂
(139.7)
1
¹⁄₂
(38.1)
10/7.5
RAWW-3470
4 (101.6)
³⁄₄
- 10
7 (117.8)
3 (76.2)
10/9.2
RAWW-34100 1
³⁄₄
(44.5)
³⁄₄
- 10
10 (254.0)
6 (152.4)
10/13.5
RAWW-10090 2
¹⁄₂
(63.5)
1 - 8
9 (228.6)
3
¹⁄₂
(88.9)
5/11.4
Item #
Bolt Size-
Threads per (in.)
Drill Bit Size
in. (mm)
Thread Depth
in. (mm)
Embedment Min. Hole
Depth in. (mm)
Qty/Wt. per
Box (lbs.)
RARM-14
¹⁄₄
- 20
³⁄₈
(9.5)
1 (25.4)
100/2.6
RARM-38
³⁄₈
- 16
¹⁄₂
(12.7)
1
⁵⁄₈
(41.3)
50/3.4
RARM-12
¹⁄₂
- 13
⁵⁄₈
(15.9)
³⁄₄
(19.1)
2 (50.8)
50/5.8
RASSRM-12
¹⁄₂
- 13
⁵⁄₈
(15.9)
³⁄₄
(19.1)
2 (50.8)
50/5.8
