POWERS FASTENERS
Split Drive Type
Anchors
Carbon Steel
Drive®
•
Base material: Concrete, stone
•
The Drive® is a one piece tamper-proof, pre-expanded anchor
available in carbon steel for use in concrete and stone
•
Tie-Wire Drive® anchors are used for suspended ceiling
applications
•
The flat head (counter-sunk) style is particularly suited for
wood-to-concrete anchoring
•
The round head style is for all other applications requiring fast,
permanent installations
POWERS FASTENERS
Toggle Bolt
•
The Toggle Bolt is a spring wing
type hollow wall anchor designed
for use in block, wallboard and
other hollow base materials; the
Toggle Bolt is a two-part assembly consisting of a machine screw
and a spring wing toggle
•
The Toggle wing is a permanently pre-assembled unit consisting
of four parts: two precision-stamped steel wings attached to a
threaded trunnion nut and a pre-stressed high-tensile coil spring
•
As the anchor is tightened, the wing configuration is designed to
sit flat against the underside of the wall, providing even distribution
of loading to prevent pull-through
POWERS FASTENERS
Strap-Toggle™
Hollow Wall Anchor
•
The Strap-Toggle™ is a
pre-assembled anchor consisting of a carbon steel wing and a
locking cap/ratchet leg assembly molded from engineered plastic
•
When compared to traditional toggles, this unique anchor can be
installed through a smaller hole and does not require a fixture or
screw to set in the base material
POWERS FASTENERS
Anchor Fasteners
Plastic Bantam Plug
Plastic anchor designed for use with
lightweight fixtures using a sheet metal
or wood screw. A flange formed at the
top end of the anchor body allows it to
be used in hollow base materials of
concrete, block, brick and wallboard. It should not be used overhead.
Priced per hundred and sold in full box quantities only.
Size: 10-12 x 1”, Drill Dia: 1/4”, Min. depth: 1”
•
Use in concrete, block, brick, wallboard
•
Use with sheet metal or wood screw
•
Made of corrosion-resistant plastic
•
Layout or hole spotting required
•
Light duty
•
Collar for hollow material
•
Available in kits, includes 100 plugs and slotted/Phillips sheet
metal screws, and one Rawl rotary carbide drill bit
•
Screw length is equal to work thickness plus anchor length
POWERS FASTENERS
Wallboard Anchor
Zip-It®
•
The Zip-It® anchor is a one piece
self drilling anchor designed for use in hollow gypsum wallboard
for light duty loads, it is available in both engineered nylon and
Zamac alloy for use with No. 8 screws in 3/8” to 1” wallboard
•
During installation, the unique drill tip of the Zip-It® uses four offset
blades to ensure fast and true cutting
•
Two blades are cutting blades and the other two are guide blades
that stabilize the anchor for speed and accuracy during installation
•
The holding capacity of the anchor is achieved through a unique
thread design
•
Thin, knife-like threads have an oversized outer diameter that cuts
deeply and cleanly into the wallboard to spread the load over a
large bearing area while the tapered root of the threaded section
compacts the wall material around the anchor to further increase
the load capacity
•
Once fully seated, the collar of the Zip-it® sets flush to the surface
of the wallboard
•
Standard box: 100
Item # Size (in.) Drill Dia. (in.) Min. Depth (in.) Std. Box
RL3631
³⁄₈
x 2
¹⁄₂
³⁄₈
1
⁷⁄₈
25
RL3691
³⁄₈
x 3
¹⁄₂
³⁄₈
1
⁷⁄₈
25
RL3272
¹⁄₄
x 2
¹⁄₄
1
¹⁄₈
100
RL3302
¹⁄₄
x 2
¹⁄₂
¹⁄₄
1
¹⁄₈
100
RL3332
¹⁄₄
x 3
¹⁄₄
1
¹⁄₈
100
RL3362
¹⁄₄
x 3
¹⁄₂
¹⁄₄
1
¹⁄₈
100
RL3392
¹⁄₄
x 4
¹⁄₄
1
¹⁄₈
100
Item #
Size (in.)
Drill Dia. (in.)
RL4131
³⁄₁₆
x3
¹⁄₂
RL4141
³⁄₁₆
x4
¹⁄₂
RL4231
¹⁄₄
x3
⁵⁄₈
RL4241
¹⁄₄
x4
⁵⁄₈
RL4441
³⁄₈
x4
⁷⁄₈
Item #
Size (in.)
Drill Dia. (in.)
Std. Box
RL4054
¹⁄₄
x 4
¹⁄₂
50
RL4056
³⁄₈
x 4
³⁄₄
25
Item #
Size (in.)
Drill Dia.
(in.)
Min. Dpth.
(in.)
RL7559
#6-8x
³⁄₄
³⁄₁₆
³⁄₄
RL7569 #8-10x
⁷⁄₈
³⁄₁₆
⁷⁄₈
RL7579 #10-12x1
¹⁄₄
1
RL7589 #14-16x1
¹⁄₂
⁵⁄₁₆
1
¹⁄₂
Item #
Desc.
Type
RL2345 Standard Box, No Screws Nylon
RL2346Z Standard Box, No Screws Zinc
RL2349 Standard Box No. 8 x 1”
screws
Zinc
