Anchors & Fastener Systems
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
BUILDEX
Teks® Select™
Fasteners
Selectively hardened self-drilling
fasteners for attaching similar or
dissimilar metals with Grade 5
performance.
•
Grade 5 Performance: Designed
to attach similar or dissimilar metals, Teks Select™ fasteners have
strength and ductility performance similar to Grade 5 Bolts; these
characteristics in the fasteners load-bearing area improve
resistance to shear failure due to wind and other loads requiring
mechanical flex (ductility)
•
Twice as Fast As Nuts And Bolts: Installs in half the time required
for nuts and bolts; replaces four installation steps with one
•
Selective Hardening: The drill point and lead threads are hard
(HRC 52) enough to drill through steel; the load-bearing area
remains soft (HRC 28-34) enough to remain ductile and resist
hydrogen assisted stress cracking
•
Climaseal ACR: Climaseal Advanced Corrosion Resistance
coating enables Teks Select™ to out perform other selectively
hardened fasteners in a 5% neutral salt spray
•
Quick Start Drill Point And Efficient Self-Tapping Thread Design:
These features combine to enable Teks Select™ to drill and tap up
to 40% faster than other selectively hardened, drilling and tapping
fasteners
•
These features also enable Teks Select™ to drill and tap with
fewer stalls than other selectively hardened fasteners
BUILDEX
Teks® Self-Drilling Fasteners
Light-Duty Steel-to-Steel Applications, Teks® 1 & Teks® 2
Applications:
•
Stitch roof deck and wall panel sidelaps
•
HVAC, electrical trim accessories to steel framing
•
Residential steel frame construction
•
Brick ties to steel framing
•
Track to stud and stud splicing
•
Hat channel to stud
Head Styles: Hex Washer Head, Oval Head, Pan Head, Hex Washer Head With Serrations
Item #
Desc.
Head Style Drill Point
Drilling Cap.
(in.)
Max Load Bearing Area
(in.)
Installation Tool
RABX1076000 10-16X
³⁄₄
”
HWH
3
.150
.500
⁵⁄₁₆
” Driv-Tru™ Socket (P/N 1513910)
RABX1112000 12-14X
⁷⁄₈
”
HWH
3
.187
.470
⁵⁄₁₆
” Driv-Tru™ Socket (P/N 1513910)
RABX1080000 12-14X1”
HWH
3
.187
.500
⁵⁄₁₆
” Driv-Tru™ Socket (P/N 1513910)
RABX1132000 12-14X1”
UPFH**
3
.187
.500
#3 Phillips Bit
RABX1114000 12-14X1
¹⁄₂
”
HWH
3
.187
1.000
⁵⁄₁₆
” Driv-Tru™ Socket (P/N 1513910)
RABX1117000 12-14X2”
HWH
3
.187
1.500
⁵⁄₁₆
” Driv-Tru™ Socket (P/N 1513910)
RABX1119000
¹⁄₄
-14X1”
HWH
3
.210
.450
³⁄₈
” Driv-Tru™ Socket (P/N 1574910)
RABX1121000
¹⁄₄
-14X1
¹⁄₂
”
HWH
3
.210
.950
³⁄₈
” Driv-Tru™ Socket (P/N 1574910)
RABX1124000
¹⁄₄
-20X1
¹⁄₈
HWH
4
.210-.312
.500
³⁄₈
” Driv-Tru™ Socket (P/N 1574910)
RABX1125000
¹⁄₄
-20X1
¹⁄₂
”
HWH
4
.210-.312
.830
³⁄₈
” Driv-Tru™ Socket (P/N 1574910)
RABX1078000
¹⁄₄
-20X2”
HWH
4
.210-.312
1.330
³⁄₈
” Driv-Tru™ Socket (P/N 1574910)
RABX1126000
¹⁄₄
-20X2
¹⁄₂
”
HWH
4
.210-.312
1.830
³⁄₈
” Driv-Tru™ Socket (P/N 1574910)
**Undercut Phillips Flat Head
Item #
Desc.
Head Style Drill Point
Max. Material Attachments Drill and Tap Capacity Box Qty.
RABX1208200 6-20x
³⁄₈
”
Pan
#2
.100
.036-.100
20,000
RABX1563200 6-20x
³⁄₈
”
HWH
#2
.036-.100
20,000
RABX1527200 6-20x
¹⁄₂
”
Pan
#2
.036-.100
20,000
RABX1210200 8-18x
¹⁄₂
”
Pan
#2
.205
.036-.100
10,000
RABX1213200 8-18x
³⁄₄
”
Pan
#2
.455
.036-.100
10,000
RABX1218200 8-18x1”
Pan
#2
.705
.036-.100
8,000
RABX1196200 8-18x
¹⁄₂
”
HWH
#2
.205
.036-.100
10,000
RABX1199200 8-18x
⁵⁄₈
”
HWH
#2
.330
.036-.100
10,000
RABX1200200 8-18x
³⁄₄
”
HWH
#2
.455
.036-.100
10,000
RABX1202200 8-18x1”
HWH
#2
.705
.036-.100
8,000
RABX1204200 8-18x1
¹⁄₂
”
HWH
#2
1.205
.036-.100
4,000
RABX1107053 10-16x
³⁄₄
”
HWH
#1
.220
.018-.095
5,000
RABX1109053 12-14x
³⁄₄
”
HWH
#1
.205
.018-.095
4,000
RABX1399053
¹⁄₄
-14x
⁷⁄₈
”
HWH
#1
.380
.018-.095
5,000
