Self-Drilling Screws
Bugle Head
•
For attaching gypsum board to 20-14 gauge steel studs
•
No. 2 Reduced Phillips Recess
•
Available in zinc and black phosphate
Self-Drilling Screws
Trim Head
•
For attaching wood trim over gypsum to 20-14 gauge metal
•
No. 1 or 2 Square Recess
Self-Drilling Screws
Pancake Framer
•
For attaching 20-14 gauge steel track to 20-16 gauge steel studs
•
No. 2 Reduced Phillips Recess
Self-Drilling Screws
Low Profile Truss
•
Low profile 20-16 gauge framer
•
No. 10 diameter for added shear strength
•
With serrations to reduce spin out
•
No. 2 Reduced Phillips Recess
Self-Drilling Screws
Modified Truss
•
For attaching metal lath in stucco and other applications 20 20-16
gauge steel studs
•
No. 2 Reduced Phillips Recess
Self-Drilling Screws
Hex Washer Head 1/4” Dr.
#2 Drilling Point
•
Metal to metal fastening used in sheet metal and light steel
framing
•
Very common in HVAC duct work assembly
Self-Drilling Screws
Hex Washer Head 5/16
Drive #3 Drilling Point
•
Metal to metal fastening used in medium gauge metal to metal
framing
•
Commonly used by sheet metal and HVAC contractors and
fabricators
Self-Drilling Screws
Hex Washer Head 5/16 Drive
#3 Drilling Point
•
Metal to metal fastening used in sheet metal to attach purlins and
channels to structural studs
•
Commonly used in up to 5 gauge steel
Item #
Size
Box Qty.
Zinc
PRMSDZ258
8X2
⁵⁄₈
2M
Black Phosphate
PRMSD114
6X1
¹⁄₄
8M
PRMSD1145
6X1
¹⁄₄
5#
PRMSD158
6X1
⁵⁄₈
5M
PRMSD1585
6X1
⁵⁄₈
5#
PRMSD178
6X1
⁷⁄₈
4M
PRMSD1785
6X1
⁷⁄₈
5#
PRMSD238
8X2
³⁄₈
3M
Item #
Size
Box Qty.
PRMTHDZ2145 6X2
¹⁄₄
5#
Item #
Size
Box Qty.
PRMPPH10585 10X
⁵⁄₈
5#
Item #
Size
Box Qty.
PRMFT1034 10x
³⁄₄
7.5M
Item #
Size
Box Qty.
PRMMTD812
8x
¹⁄₂
10M
PRMMTD8125
8X
¹⁄₂
5#
PRMMTD8114 8X1
¹⁄₄
6M
PRMMTD81145 8X1
¹⁄₄
5#
PRMMTD1034 10X
³⁄₄
5M
Item #
Size
Box Qty.
PRMHWD812
8X
¹⁄₂
10M
PRMHWD834
8X
³⁄₄
10M
Item #
Size
Box Qty.
PRMHWD1012
10X
¹⁄₂
8M
PRMHWD1034
10X
³⁄₄
6M
PRMHWD10345
10x
³⁄₄
5#
PRMHWD10100
10X1
5M
PRMHWD101005
10X1
5#
PRMHWD101125
10X1
¹⁄₂
5#
Item #
Size
Box Qty.
PRMHWD120345
12X
³⁄₄
5#
PRMHWD12100
12X1
3M
PRMHWD121005
12X1
5#
PRMHWD121125 12X1
¹⁄₂
5#
PRMHWD122005
12X2
5#
