BUILDEX
Sammys® For Cracked Concrete
Sammys®
•
Self-tapping screw anchor for cracked concrete, seismic and standard applications
•
Patented Advanced Threadform Technology reduces installation torque and increases pullout performance
•
Vertical anchor complies with:
•
ICC-ESR-2202, Cracked Concrete/Seismic
•
2012, 2009 International Building Code (IBC)
•
2012, 2009 International Residential Code (IRC)
•
Uniform Building Code
•
City of Los Angeles (COLA)* pending
•
Vertical anchor use #14 Black Nut Driver #8113910, Horizontal anchor use #14 Red Nut Driver #8114910, Swivel anchor use #14 SH Orange
Nut Driver # 8273910
BUILDEX
Concrete/Wood
Installation Kit
Sammys®
•
Includes: (1 each) #14 Black Nut
Driver, #14 SW Red Nut Driver,
#250 Bit (1/4"), SDS Bit (1/4"),
7/32 Wood Bit, HEX 250 Bit
Receiver (1/4") and SL 250
Sleeve
BUILDEX
Speedy Pole Tool™
Sammys®
•
Ideal for retrofit and hard-to-reach projects in wood and steel
•
Hang it high from down low
BUILDEX
#14 Nut Driver
Sammys®
BUILDEX
Speedy Pole Tool™
Socket Kit
Sammys®
•
Used with Sammys® Speedy Pole
Tools™
•
8129910 includes: (1 of each)
Adaptor Plug, Socket Driver for
Sammys®, Socket Driver for Ceiling
Wire Screws, Socket Driver for 1/4”
Standard Nut Drivers, Stuf Plug for
Viper or Ladd Powder Actuated Attachment
BUILDEX
Toggle for Drywall
or Concrete
Sammys®
Installation Instructions:
•
1. Pre-drill a 5/8” hole with a regular drill or hole saw
•
2. Insert SST screw into #14 Black Nut Driver # 8113910 with wing
nut and washer on bolt, insert wing nut through surface, and begin
installation
•
3. When bolt is secure and nut driver spins free, stop drill motor
and remove
•
4. SST screw is now ready to receive 1/4”, 3/8”, or Metric all thread
rod or bolt stock
Item #
Model
Applicatrion Size (in.) Rod Size (in.) Ultimate Pullout (lbs.)
RABX8306957 CCST 516 Vertical
⁵⁄₁₆
-14 x 2
¹⁄₂
³⁄₈
857
RABX8307957 SW-CCST 516 Horizontal
⁵⁄₁₆
-14 x 2
¹⁄₂
³⁄₈
857
RABX8308957 SH-CCST 516 Swivel
⁵⁄₁₆
-14 x 2
¹⁄₂
³⁄₈
857
Item #
Desc.
RABX8122910 Concrete Installation Kit
RABX8121910 SDS B250 Bit Receiver (
¹⁄₄
”)
Item #
Length (ft.)
RABX8123910
6
RABX8124910
12
RABX8125910
18
RABX8126910
24
Item #
Color
RABX8113910 Black
RABX8114910
Red
RABX8273910 Orange
Item #
Desc.
RABX8127910
Sammys® Socket Driver
RABX8128910 Ceiling Wire Socket Driver
for Wire and Chain
RABX8129910 Universal Pole Tool Socket Kit
Item #
Model
Size
(in.)
Rod
Size
(in.)
Ultimate
Pullout (lbs.)
RABX8063925 SST 300
¹⁄₄
x3
¹⁄₄
450 (Lath & Plaster)
404 (2 Layers
⁵⁄₈
” Rock)
RABX8064925 SST 30
¹⁄₄
x3
³⁄₈
450 (Lath & Plaster)
404 (2 Layers
⁵⁄₈
” Rock)
