POWERS FASTENERS
Power-Stud+™ SD2
Wedge Type Expansion
Anchor
•
Base Material: Normal-Weight Concrete, Structural Sand-Light-
weight Concrete, Concrete over Metal Deck, Grout-Filled Masonry
•
Anchor Material: Zinc-plated Carbon Steel Body with Stainless
Steel Expansion Clip
•
The {Power-Stud+SD2 anchor is a fully threaded,
torque-controlled, wedge expansion anchor which is designed for
consistent performance in cracked and uncracked concrete
•
CRACKED CONCRETE APPROVALS
•
Code Listed: ICC-ES ESR-2502
POWERS FASTENERS
Steel Dropin
Stainless Steel
•
Type 304 Stainless Steel Dropin
POWERS FASTENERS
Wedge-Bolt®+ Screw
Anchor
Carbon Steel
Wedge-Bolt®
•
INSTALL WITH POWERS WEDGE BIT
•
Base Material: Normal-Weight Concrete, Structural Sand-Light-
weight Concrete, Concrete Over Metal Deck, Grouted CMU
•
Anchor is made of Zinc Plated Carbon Steel with a Hex Head
•
The Wedge-Bolt®+ anchor is a one piece, heavy-duty screw
anchor with a finished hex head
•
Simple to install, easy to identify and fully removable
•
Designed for consistent and reliable performance in CRACKED
AND UNCRACKED CONCRETE
•
Code Approvals: ESR-2526 (Concrete), ESR-1678 (CMU)
Item # Size ( in.)
Thread
Length (in.)
Std. Box
RL7413SD2
³⁄₈
X3
1
⁵⁄₈
50
RL7414SD2
³⁄₈
X3
¹⁄₂
2
¹⁄₄
50
RL7415SD2
³⁄₈
X3
³⁄₄
2
¹⁄₂
50
RL7416SD2
³⁄₈
X5
3
³⁄₄
50
RL7422SD2
¹⁄₂
X3
³⁄₄
2
¹⁄₈
50
RL7423SD2
¹⁄₂
X4
¹⁄₂
2
⁷⁄₈
50
RL7424SD2
¹⁄₂
X5
¹⁄₂
2
⁷⁄₈
50
RL7426SD2
¹⁄₂
X7
5
³⁄₈
25
RL7427SD2
¹⁄₂
X8
¹⁄₂
6
⁷⁄₈
25
RL7435SD2
⁵⁄₈
X4
³⁄₄
2
⁷⁄₈
25
RL7433SD2
⁵⁄₈
X5
3
¹⁄₈
25
RL7434SD2
⁵⁄₈
X6
4
¹⁄₈
25
RL7436SD2
⁵⁄₈
X7
5
¹⁄₈
25
RL7438SD2
⁵⁄₈
X8
¹⁄₂
6
⁵⁄₈
25
RL7442SD2
³⁄₄
X5
¹⁄₂
3
¹⁄₄
20
RL7444SD2
³⁄₄
X6
¹⁄₄
4
20
RL7446SD2
³⁄₄
X7
4
³⁄₄
20
RL7448SD2
³⁄₄
X8
¹⁄₂
6
¹⁄₄
10
Item #
Size
(in.)
Drill Dia.
(in.)
Min.
Depth (in.)
Thread
Depth (in.) Std. Box
RL6206
³⁄₈
¹⁄₂
1
⁹⁄₁₆
⁵⁄₈
50
RL6208
¹⁄₂
⁵⁄₈
2
¹³⁄₁₆
50
Item #
Dia. Size &
Length (in.)
Min. Embed.
(in.)
Std. Box
RL7204SD
¹⁄₄
x 1
¹⁄₄
1
100
RL7206SD
¹⁄₄
x 1
³⁄₄
1
100
RL7208SD
¹⁄₄
x 2
¹⁄₄
1
³⁄₄
100
RL7210SD
¹⁄₄
x 3
1
³⁄₄
100
RL7220SD
³⁄₈
x 1
³⁄₄
1
¹⁄₂
50
RL7222SD
³⁄₈
x 2
¹⁄₂
2
¹⁄₈
50
RL7224SD
³⁄₈
x 3
2
¹⁄₈
50
RL7226SD
³⁄₈
x 4
2
¹⁄₈
50
RL7228SD
³⁄₈
x 5
2
¹⁄₈
50
RL7230SD
³⁄₈
x 6
2
¹⁄₈
50
RL7240SD
¹⁄₂
x 2
1
³⁄₄
50
RL7242SD
¹⁄₂
x 2
¹⁄₂
2
50
RL7244SD
¹⁄₂
x 3
2
¹⁄₂
50
RL7246SD
¹⁄₂
x 4
2
¹⁄₂
50
RL7248SD
¹⁄₂
x 5
2
¹⁄₂
25
RL7250SD
¹⁄₂
x 6
2
¹⁄₂
25
RL7268SD
¹⁄₂
x 6
¹⁄₂
2
¹⁄₂
25
RL7252SD
¹⁄₂
x 8
2
¹⁄₂
25
RL7260SD
⁵⁄₈
x 3
2
¹⁄₂
25
RL7262SD
⁵⁄₈
x 4
3
¹⁄₄
25
RL7264SD
⁵⁄₈
x 5
3
¹⁄₄
25
RL7266SD
⁵⁄₈
x 6
3
¹⁄₄
25
RL7270SD
⁵⁄₈
x 8
3
¹⁄₄
25
RL7280SD
³⁄₄
x 3
2
¹⁄₂
20
RL7282SD
³⁄₄
x 4
3
20
RL7284SD
³⁄₄
x 5
4
¹⁄₄
20
RL7286SD
³⁄₄
x 6
4
¹⁄₄
20
RL7288SD
³⁄₄
x 8
4
¹⁄₄
10
RL7290SD
³⁄₄
x 10
4
¹⁄₄
10
