Seismic Wedge Anchors
Trubolt® +
Trubolt® + Wedge anchors consist of a high-strength threaded stud body, expansion clip, nut and washer. Anchor bodies are made of
plated carbon steel. The expansion clip consists of a split cylindrical ring with undercutting grooves.
•
The exposed end of the anchor is stamped to identify anchor length. Stampings should be preserved during installation for any
subsequent embedment verifification
•
Use carbide tipped hammer drill bits made in accordance with ANSI B212.15-1994 to install anchors
•
ICC Evaluation Service, Inc. # ESR-2427
•
Category 1 performance rating
•
2006 IBC and 2009 IBC compliant
•
Meets ACI 318 ductility requirements
•
Tested in accordance with ACI 355.2 and ICC-ES AC193
•
For use in seismic zonesA, B, C, D, E, & F
•
3/8", 1/2", 5/8" & 3/4" diameter anchors
•
listed in ESR-2427
•
City of Los Angeles - #RR25867
•
2009 IBC Compliant
Item #
Thread
Length (in.)
Anchor Dia. (in.) & Drill Bit Size
(Threads) per Inch
Overall
Length (in.)
Max Thickness of Material to
be Fastened in. (mm)
Qty/Wt per Box
(lbs.)
RACWS-3830
1
⁵⁄₈
³⁄₈
-16
3 (76.2)
⁵⁄₈
(15.9)
50/5.3
RACWS-3836
2
³⁄₈
³⁄₈
-16
3
³⁄₄
(95.3)
1
³⁄₈
(34.9)
50/5.9
RACWS-3850
3
⁵⁄₈
³⁄₈
-16
5 (127)
2
⁵⁄₈
(66.7)
50/7.3
RACWS-1236
2
¹⁄₈
¹⁄₂
-13
3
³⁄₄
(95.3)
³⁄₄
(19.1)
25/5.7
RACWS-1244
2
⁷⁄₈
¹⁄₂
-13
4
¹⁄₂
(114.3)
1
¹⁄₂
(38.1)
25/7
RACWS-1254
3
⁷⁄₈
¹⁄₂
-13
5
¹⁄₂
(139.7)
2
¹⁄₂
(63.5)
25/8
RACWS-1270
5
³⁄₈
¹⁄₂
-13
7 (177.8)
4 (101.6)
25/9.2
RACWS-5850
3
³⁄₁₆
⁵⁄₈
-11
5 (127)
1
¹⁄₈
(28.6)
10/4.7
RACWS-5860
4
³⁄₁₆
⁵⁄₈
-11
6 (152.4)
2
¹⁄₈
(54)
10/5.4
RACWS-5870
5
³⁄₁₆
⁵⁄₈
-11
7 (177.8)
3
¹⁄₈
(79.4)
10/6.2
RACWS-5884
5
³⁄₄
⁵⁄₈
-11
8
¹⁄₂
(215.9)
4
⁵⁄₈
(117.5)
10/8
RACWS-3454
3
⁵⁄₈
³⁄₄
-10
5
¹⁄₂
(139.7)
1
¹⁄₂
(38.1)
50/7.6
RACWS-3462
4
³⁄₈
³⁄₄
-10
6
¹⁄₄
(158.8)
2
¹⁄₄
(57.2)
10/8.5
RACWS-3470
5
¹⁄₈
³⁄₄
-10
7 (177.8)
3 (76.2)
10/9
RACWS-3484
5
³⁄₄
³⁄₄
-10
8
¹⁄₂
(215.9)
4
¹⁄₂
(114.3)
10/10.5
RACWS-34100
5
³⁄₄
³⁄₄
-10
10 (254)
6 (152.4)
10/11.9
Check with your Edge rep for detailed
Specification information
