Anchors & Fastener Systems
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
ITW REDHEAD
Powder Fasteners
Semi-Automatic
Ramset®
•
30% faster overhead attachment
Advantages:
•
No cycling eliminates wasted
loads-work faster and save money
•
Super quiet-work in occupied
buildings without disturbing
occupants
•
Weighs just 3 pounds-four pounds
lighter than other
manufacturer's tool. Increases productivity
•
Easy to use-just position, then push to fire. No trigger. No broken
cables. No pinched fingers
Specifications
•
.27 caliber, 10-shot strip loads 3 (green), 4 (yellow), 5 (red)
•
Pin Capacity Ceiling Clips: 1-1/4 in. (match nosepiece with pin)
ITW REDHEAD
.27 Caliber Strip Tool
Semi-Automatic
•
3” Pin Capacity
•
Very powerful
•
Spring return front end - no manual resetting of the piston
•
Power adjust - dial down 1-1/2 load levels
•
Rugged soft grip handle
•
Low recoil
•
Ergonomically balanced
•
3 Year Warranty
Specifications:
•
.27 caliber strip loads 3 (Green), 4 (Yellow), 5 (Red)
•
Weight: 5.5 lbs.
•
Length: 19”
•
Muzzle Bushing O.D.: 7/8”
ITW REDHEAD
D60
Powder Actuated Nailer
Advantages:
•
Quick power adjustment-gives
eight levels of power with only one
load level for a variety of applica-
tions
•
Rugged polyamide housing-reduces heat transfer and maximizes
user comfort
•
Soft, recoil-absorbing handle-for increased operator comfort
•
Ramset Disc Technology-loads only advance after firing;
eliminates 10-20% of load waste
•
5 year warranty
ITW REDHEAD
Drive Pins
Powder Actuated
ITW Ramset/Red head powder actuated
fasteners are specifically fabricated to
meet the exacting requirements of
toughness and durability that enable them to penetrate dense
concrete and structural quality steel.
Designed for use in concrete and structural steel applications. 100
pin pack
.300 head diameter drive pins
Shank diameter = .145
ITW REDHEAD
Ramguard Pins
•
Designed for use in treated lumber
applications
•
100 per box
•
Shank diameter = .145 Head diameter = .300
ITW REDHEAD
Drive Pins w/Washers
•
Washer increases bearing
surface against the material to be
fastened
•
16 Ga. metal washer (100 per
box)
•
Shank diameter = .145 Head
diameter = .300
Item #
Load Type
Max. Pin Length Weight (lbs.)
RAVIPER .27 Caliber,
10 Shot Strip Loads
1
¹⁄₂
”
4.5
Item #
RAXT540
Item #
Load Type
Max. Pin Length Weight (lbs.)
RAD60 .25 Caliber,
10 Shot Disc Loads
2
³⁄₈
” (2
¹⁄₂
” with
washer
4.9
Item # Shank Length in. (mm)
RA1503K
¹⁄₂
Knurled (12.7)
RA1506
³⁄₄
(19.1)
RA1508
1 (25.4)
RA1510
1
¹⁄₄
(31.8)
RA1512
1
¹⁄₂
(38.1)
RA1514
2 (50.8)
RA1516
2
¹⁄₂
(63.5)
RA1524
3 (76.2)
Item #
Shank Length (in.)
RA1516SDE 2
¹⁄₂
w/washer
RA1524SDE 3 w/washer
Item #
Shank Length (in.)
RA1508SD
1
RA1510SD
1
¹⁄₄
RA1512SD
1-
¹⁄₂
RA1514SD
2
RA1516SDC
2
¹⁄₂
RA1524SDC
3
