605
SIMPSON STRONG-TIE®
ITS Top Flange Hangers
Engineered Wood Products Hangers
•
The innovative ITS sets a new standard for
engineered wood top flange hangers. It installs
faster and uses fewer nails than any other
EWP top flange hanger
•
The new Strong-Grip™ seat and Funnel
Flange™ features allow standard joist
installation without requiring joist nails resulting
in the lowest installed cost
•
The Strong-Grip seat firmly secures I-joists
with flange thicknesses from 1-1/8” to 1-1/2”
•
Material: 18 gauge
•
Finish: Galvanized
Allowable Loads:
•
ITS hangers have locations for optional nails if additional uplift is
needed. Optional uplift nailing requires the addition of properly
secured web stiffeners
Options:
•
Because these hangers are fully die-formed, they cannot be
modified. However these models will normally accommodate a
skew of up to 5°
SIMPSON STRONG-TIE®
LBV I Top Flange Hangers
I-Joist and Structural Composite Lumber Hanger
•
The newly improved LBV hanger offers offers
wide versatility for I-joists and structural
composite lumber
•
The enhanced load capacity widens the range
of applications for these hangers
•
The LBV features positive angle nailing and
does not require the use of web stiffeners for
standard non-modified I-joist applications
•
Finish: Galvanized; all saddle hangers and all
welded sloped and special hangers - Simpson
Strong-Tie® gray paint. It may also be ordered
in HDG finish
Options:
•
Other widths are available; specify W
dimension (the minimum W dimension is 1-9/16)
SIMPSON STRONG-TIE®
LSSU Light Slopeable/Skewable U Hangers
for I-Joists and SCL
•
Attaches joists or rafters to headers,
sloped up or down, and skewed left
or right , up to 45°
•
18 Gauge
•
Finish: Galvanized
SIMPSON STRONG-TIE®
STC/DTC Roof Truss Clips
For alignment control between a roof truss and
nonbearing walls; the 1 1/2" slot permits vertical
truss chord movement when loads are applied.
Material: 18 gauge.
1. Loads may not be increased for short-team
loading.
2.Truss or rafter must be bearing on top plate to
achieve the allowable loads under "without gap."
3. Installed with maximum 1/4" space between
rafter or truss and top plate under "with 1/4 gap". Where loads are not
required, space is not limited to 1/4".
SIMPSON STRONG-TIE®
MST Strap Tie
•
Straps are designed to transfer tension loads in a wid
e variety of applications
•
Splitting may be a problem with installations on lumber
smaller than 3-1/2”, either fill fill every nail hole with
10dx1-1/2” nails or fill every other hole with 16d common
nails
•
Reduce the allowable load based upon the size and
quantity of fasteners used
SIMPSON STRONG-TIE®
TS Twist Straps
Twist straps provide a tension connection between two
wood members. An equal number of right and left hand
units are supplied in each carton.
Material: 16 gauge.
Some products available in stainless steel and Z-MAX.
1. Install half of the fasteners on each end of the strap to
achieve full loads.
2. Loads have been increased 33% and 60% for
earthquake or wind loading; no further increase allowed.
3. 16d sinkers (9 ga x 3 1/4") may be substituted for the
specified 16d commons at 0.84 of the table loads.
L: 17 3/4, Fasteners (Total): 14-16d, Allowable Loads (133 & 160):
930
SIMPSON STRONG-TIE®
CS Coiled Straps
•
Continuous utility strap which can be cut to
length on the job site
•
Finish: Galvanized. Some products available
in ZMAX® coating
