Anchors & Fastener Systems
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
PNEUTEK
Portable
Air Compressors
PNEUTEK
Auxiliary Tank
•
17 gallon ASME tank assembly
•
Equipped with pressure regulator,
safety valve, male connector and
female coupler
PNEUTEK
1/2” Head Dia.
Fasteners
•
Knurled fasteners for steel dock
•
Pre-collated in color-coded strips of 10
•
Easily loaded in magazine which holds 30 fasteners
•
2500 per carton
PNEUTEK
Air Hose
•
1/2” x 100 ft., 300 PSI air hose
assembly
•
3/8” female coupler and 3/8”
male connector
SIMPSON STRONG-TIE®
SSTB Anchor Bolts
•
The SSTB anchor bolt is desgned
for maximum performance as an
anchor bolt for holdowns and
Simpson Strong-Tie® Strong-
WAll® shearwalls
•
Extensive testing has been done to
determine the design load capacity
of the SSTB when installed in
many common applications
•
The SSTB anchor bolts are now
code listed by ICC-ES under the
2006 and 2009 IBC® and IRC® to
meet the requirements of ICC-ES acceptance criteria - ACC-399.
ICC-ES ESR-2611 is the industry’s first code report issued for
proprietary anchor bolts
evaluated to the criteria of AC 399
Special Features:
•
Identification on the bolt head showing embedment angle and
model
•
Offset angle reduces side bursting, and provides more concrete
cover
•
Rolled thread for higher tensile capacity
•
Stamped embedment line aids installation
•
Available in HDG for additional corrosion resistance
•
Material: ASTM F-1554, Grade 36
•
Finish: None. May be ordered in HDG; contact Simpson
Strong-Tie®
SIMPSON STRONG-TIE®
MASA Mudsill Anchors
•
Mudsill anchors have always been
a time-saving alternative to anchor
bolts, and the new MASA anchors
provide even greater load-carrying
capacity than our original MAS
•
The MASA provides an alternative
for 5/8” and 1/2” mudsill anchor
bolts on 2x, double 2x and 3x
mudsills
•
It eliminates the need for 3” square
washers for seismic design and, in some cases, has load
capacities that meet or exceed the parallel and perpendicular to
plate shear capacity of other cast-in-place anchors
•
Two versions of the MASA are available-the standard MASA for
installation on standard forms and the MASAP for panelized forms
•
The MASA and MASAP are code listed by ICC-ES under the 2006
and 2009 IBC® and IRC® and have been tested to meet the
requirements of ICC-ES acceptance criteria AC-398 for cracked
and uncracked concrete
•
Material: 16 gauge
•
Finish: Galvanized, all available in ZMAX® coating
Item #
Description
Output
PIPC-2S13KES-20 Two-stage,
12.5 hp. Kohler
engine
20 cfm @ 175 psig`
PIPC-2S22KES-40 Two-stage
22 hp. Kohler
engine
39.5 cfm @ 175 psig
Item #
PIATA-17
Item #
Diame-
ter (in.)
Length
(in.)
Steel
Substrate
Thickness (in.)
For Tool
No.
PISDK61075 .142
³⁄₄
.113 to .155 PT-400Z
PISDK63075 .172
³⁄₄
.155 to .250 PT-400Z,
PT-1500Z
PIK64062
.182
⁵⁄₈
.188 to .312 PT-1500Z
PIK66062
.200
⁵⁄₈
.281 and up PT-1500Z
Item #
PIAHA-100
