599
ITW REDHEAD
Threaded Rod Hanger
Ramset®
•
For suspended ceilings, piping and
other items using 1/4 or 3/8 threaded
rod
•
16 Ga. threaded rod hanger (100 per
box)
•
Shank diameter = .125/.150 Head
diameter = .300
ITW REDHEAD
Semi Automatic
Fasteners
•
.25 caliber, 10-shot disc loads
ITW REDHEAD
Powder Loads
ITW Ramset/Red Head powder loads and tools
match tolerances to provide optimum power within
recognized national velocity standards. Available in
color-coded 10-load discs, 10-load strips, and
100-load boxes.
Powder Guide
Power level is designated by the load level number
marked on each box; also by the color of the box
and each powder load. As the number increases,
the power level increases.
Case Color: Brass
ITW REDHEAD
Extension Poles
Quality Ramset extension poles
provide the convenience of using
powder actuated tools for overhead
fastening without the need for scaffolding or ladders.
Advantages:
•
Rubber "motorcycle" grip for operator comfort and to reduce recoil
level
•
Encased cable runs length of pole and connects hand lever with
trigger-no rods to bend inside
•
Delrin™ coupler on cable makes pole di-electric
•
Top-quality hand lever and cable system requires only 15 pounds
of pressure so cable doesn't stretch
•
Lightweight cast aluminum housing fits tool snugly and provides
tool protection
For use with:
•
D60-our premier semi-automatic tool, featuring power level
adjustment and no-waste disc loads
•
SA270-high-quality .27 caliber strip tool for general purpose
applications
•
D45-most durable, high-power, semi-automatic tool for hard
concrete and steel applications
•
MD380-popular 3/8" head diameter tool
•
AUTOFAST-the fastest, quietest tool we make; no cocking
•
Hilti® DX36
ITW REDHEAD
Viper Extension Poles
Ramset®
•
Rubber “motorcycle” grip for operator comfort and to reduce recoil
level
•
Delrin™ coupler on cable makes pole di-electric
•
Top-quality hand lever
•
Lightweight cast aluminum housing fits tool snugly and provides
tool protection
•
Trigger bar adjusts easily for individual tools
•
Adjustable in 1’ increments
PNEUTEK
Steel Decking Tools
Stand-up Air-Safe®
•
Ergonomic stand-up tool design for comfort,
speed and convenience
•
Uni-construction fasteners for highest shear
strength and ease of inspection
•
Fastens into unlimited steel thickness
•
Lowest in-place fastener cost
•
Highest corrosion resistant fasteners
Item #
Desc.
RA14TRHSS10
¹⁄₄
" Rod hanger w/1" premium pin
RA38TRHSS10
³⁄₈
" Rod hanger w/1" premium pin
Item # Color
Wt
RA2D60 Brown 4.9
RA3D60 Green 4.9
RA4D60 Yellow 4.9
Item #
Tool
Model
Power
Level
Color Caliber
Packaging/
Box
RA22CW 721-4170 2 Brown 0.22
100
RA32CW 721-4170 3 Green 0.22
100
RA42CW 721-4170 4 Yellow 0.22
100
RA3RS27 SA270,
DX-350
3 Green 0.27 10 Strips
RA4RS27 SA270,
DX-350
4 Yellow 0.27 10 Strips
RA5RS27 SA270,
DX-350
5 Red 0.27 10 Strips
RA3RS25 DX-35 3 Green 0.25 10 Strips
RA4RS25 DX-35 4 Yellow 0.25 10 Strips
RA5RS25 DX-35 5 Red 0.25 10 Strips
RA6RS27 DX-451 6 Purple 0.27 10 Strips
Item #
Desc. (ft.)
RAPTSEMI6
6
RAPTSEMI8
8
Item #
Length (ft.)
RATVP0L612 6—12
Item #
Desc.
PIPT-400Z-ER1 1
¹⁄₂
” Magazine,
¹⁄₂
” Head Dia.
PIPT-1500Z-ER1 1
¹⁄₂
” Magazine,
¹⁄₂
” Head Dia.
